Eco Recyclable Pod EM2
Eco Recyclable Pod
model:EM2
This environmentally certified pod is made of 82% recyclable materials (6061 aluminum + PET felt), all of which meet E0 environmental standards and have passed relevant national certification. The modular design of the pod is easy to recycle, which is in line with ESG’s green building and carbon-neutral campus goals.
Product Introduction
Basic Information
Parameter | Value |
Product Name | Eco Recyclable Pod |
Model | EM2 |
External Size (mm) | 1500*1200*2300 |
Internal Size (mm) | 1355*1075*2150 |
Package Size (mm) | |
Net Weight (kg/lbm) |
Electrical Specifications
| Parameter | Value |
|---|---|
| Power Adapter | Input: 85~264VAC, 47~63Hz / 120~370VDC; Output: 24V, Max Power 100W |
| Rotary Dimmer Panel | Anodized aluminum, button-switch functions, rotary knob, long-press for manual mode |
| Lamp | 24V 1.5A, 720mm, OSRAM module, CRI 92, anti-glare index 20, low flicker |
| AC Power Outlet | 5-hole universal outlet×2, rated current 10A, rated power 1100W/110V, 2400W/240V |
| DC Power Outlet | USB-A×1 (QC 3.0), USB-C×1 (PD 20W) |
Materials & Accessories
| Parameter | Value |
|---|---|
| Main Frame | 6061 aluminum alloy, electrostatic powder coating, DuPont polymer |
| Glass | 5+5mm laminated tempered glass, edge screen print |
| Side Wall | PVC film + galvanized steel sheet + PET acoustic felt + galvanized steel sheet |
| Interior Wall Panel | 12mm PET felt acoustic board + polyester fabric |
| Carpet | Nylon fiber carpet with PVC base |
| Door Lock | Aluminum magnetic lever handle lock, anodized, key optional, external installation |
| Door Hinge | Stainless steel detachable barrel hinge, quick-deploy |
| Door Closer | Concealed cam-action door closer |
Acoustic Specifications
| Parameter | Value |
|---|---|
| Sound Insulation | DS, A29.5 |
| Noise Level (Default) | <30dB |
QBOX Acoustic Cabin: Redefining Workspace Acoustics with Intelligence
As a pioneer in modular acoustic engineering, ZOYOGU’s QBOX series delivers enterprise-grade noise control solutions through CE/SGS certified smart cabins. Serving 700+ clients across 26 countries, our patented technologies empower four core sectors: corporate, healthcare, education, and industrial.
Engineering Excellence
- Military-Grade Soundproofing: 6-layer aluminum honeycomb structure with damping felts achieves Rw+Ctr 35dB±5 precision, outperforming conventional designs by 40% in energy dissipation.
- Smart Ecosystem: IoT-enabled ventilation auto-adjusts airflow (full refresh in 2.5mins) while cutting energy use by 35% versus competitors.
- Modular Deployment: 40+ standardized components enable 72hr onsite installation, minimizing workspace disruption.
Industry-Specific Solutions
QBOX offers OEM/ODM customization for vertical needs:
- Healthcare: HIPAA-compliant consultation pods with antimicrobial surfaces
- Education: ANSI S12.60-certified exam cabins featuring EM shielding
- Industrial: Custom enclosures for 80-125dB high-frequency noise
Quality Assurance
In our 20,000㎡ ISO 9001 smart factory, each unit undergoes:
- Raw material spectrometry (ASTM E1252)
- 48hr extreme environment simulation
- Third-party acoustic validation
Backed by 15-year warranty and global spare parts network.
Sustainable Value
With 82% recyclable materials and 12.7kg CO₂ reduction per unit, QBOX is awarded “Global Green Building Preferred Product” 2023, accelerating your ESG compliance.
